Medium Format Film Photography for Beginners

Medium format film photography uses an image area larger than 35mm film and smaller than traditional large-format sheet film. For many photographers, the format begins with 120 roll film, a paper-backed film approximately 6cm wide.

The name “120” refers to the roll-film specification. It does not describe the film’s width or determine the shape of the photograph. The camera defines how much of the roll is used for each exposure, creating formats such as 6 × 4.5, 6 × 6, 6 × 7, and 6 × 9.

Each format changes the proportions of the frame, the number of exposures available, and the way space is organized before the shutter is released.

This guide explains how 120 film works, how it differs from 35mm, and what to consider when choosing, loading, exposing, developing, and scanning a first roll.

Understanding 120 Film and Medium Format Photography

How 120 Film Works

Unlike 35mm film, 120 film is not enclosed in a metal cartridge. The film is attached to protective backing paper and wound around a spool.

Inside the camera, the roll moves from the supply side to an empty take-up spool. The film gate defines the area exposed to light, while the advance mechanism controls the spacing between frames.

A roll of 120 film does not contain pre-cut frames. The same film stock can therefore be used in cameras designed for different formats. A 6 × 4.5 camera records a smaller image and provides more exposures, while a 6 × 9 camera uses more of the roll for each photograph.

The backing paper protects the film during loading and unloading. It also carries alignment marks that many cameras use to position the roll before the first exposure.

Other roll-film specifications include 220 and 620. Although they may use film of a similar width, their length, backing paper, or spool construction differs. A camera should only be loaded with the film and spool type it was designed to accept.

Digital medium format belongs to the same photographic tradition. It replaces film with an electronic sensor while retaining the emphasis on a larger imaging area, careful composition, and the finished image.

How Medium Format Differs from 35mm Film

The primary difference is the size of the recorded image.

A standard 35mm frame measures 36 × 24mm. Common medium format frames on 120 film range from approximately 6 × 4.5cm to 6 × 9cm, providing substantially more negative area.

A larger negative requires less enlargement to produce a print of the same dimensions. When film stock, exposure, development, and output are comparable, this can preserve fine detail and make grain appear less prominent.

The difference is often visible in skin, fabric, foliage, architecture, and distant landscape textures. In a carefully made print or high-quality scan, these elements can remain distinct without aggressive sharpening.

The negative provides the recording area, but technique determines how much information reaches the finished photograph. Focus, camera stability, lens performance, exposure, development, and scanning all matter.

Medium format also affects depth of field. To achieve a similar angle of view, a medium format camera generally uses a longer focal length than a 35mm camera. At the same f-number and comparable framing, this can produce a shallower depth of field.

Aperture, focal length, camera position, subject distance, background distance, and lens design all contribute to the result. The visual character associated with medium format comes from the complete optical arrangement, not the film size alone.

A roll of 35mm film commonly provides 24 or 36 exposures, while 120 film generally provides between 8 and 16. The lower frame count gives each exposure greater practical weight, while still allowing the format to be used for portraits, travel, documentary work, and moving subjects.

These are general characteristics. Results vary with the camera, lens, film, processing, and output method.

Choosing a 120 Film Format

The camera determines the frame dimensions recorded on the roll. Each format changes the number of exposures, the proportions of the photograph, and the way the frame is composed.

Traditional format names are approximate. The actual image area is usually slightly smaller than the stated dimensions.

6 × 4.5

6 × 4.5, often called 645, provides the highest frame count among these common formats.

Its 4:3 proportions may feel familiar to photographers coming from digital cameras. It offers a practical balance between negative area, camera size, and the number of photographs available on each roll.

6 × 6

6 × 6 produces twelve square photographs.

Without a fixed horizontal or vertical orientation, the square frame directs attention toward balance, spacing, and the relationship between forms. The center carries visual weight, while the corners and edges remain equally involved in the composition.

The format is closely associated with the Hasselblad V System, where the square negative and waist-level finder shaped a distinctive approach to seeing. The camera does not need to be rotated between portrait and landscape orientation, allowing attention to remain on geometry, light, and the placement of the subject.

6 × 7

6 × 7 uses more negative area for each photograph and creates proportions close to several traditional print formats.

Its frame feels expansive without becoming especially wide. It is well suited to portrait, landscape, still-life, and editorial work, particularly when the final image will be printed with minimal cropping.

6 × 9

6 × 9 produces approximately eight photographs per roll.

It shares the 3:2 aspect ratio familiar from 35mm photography while recording the image on a considerably larger negative. Its wider proportions suit landscapes, architecture, and compositions built around horizontal movement.

Other cameras may use formats such as 6 × 8, 6 × 12, or wider panoramic variations. Each offers a different relationship between negative area, frame count, and composition.

Types of Medium Format Film Cameras

Medium format cameras use several viewing and focusing systems. Each creates a different relationship between the photographer, the subject, and the frame.

Twin-Lens Reflex Cameras

A twin-lens reflex camera, or TLR, uses two vertically aligned lenses. The upper lens forms the viewfinder image, while the lower lens exposes the film.

The photographer usually composes from above through a waist-level finder. Because the camera does not need to remain directly in front of the face, portrait sessions can feel less confrontational.

With no reflex mirror moving during exposure, many TLR cameras operate quietly and with little internal vibration.

The finder image is generally reversed from left to right, which requires practice when adjusting composition or following movement. Many TLR cameras also use a fixed lens. At close distances, the separation between the viewing and taking lenses may create a small difference between the viewed and recorded image.

Single-Lens Reflex Cameras

A medium format single-lens reflex camera uses the taking lens for both viewing and exposure.

A mirror directs the image toward a waist-level finder or eye-level prism. When the shutter is released, the mirror moves out of the film path.

Viewing through the taking lens makes precise focus, close-up work, filtration, and depth-of-field assessment more direct.

Many medium format SLR systems support interchangeable lenses, finders, focusing screens, and film magazines. A waist-level finder favors a more observational style of framing, while an eye-level prism may feel more natural when following movement.

Rangefinder Cameras

A medium format rangefinder uses a separate optical viewfinder and a coupled focusing mechanism.

Focus is set by aligning two images within a central patch. Without a reflex mirror, the camera can be relatively compact and quiet.

The clear eye-level view suits travel, documentary photography, and environmental portraiture. Some designs also show part of the scene outside the final frame, helping the photographer anticipate movement.

Because the photographer does not look directly through the taking lens, close-range composition, macro work, long focal lengths, and visually assessed filters may be less direct.

Modular Medium Format Systems

A modular camera separates the system into interchangeable components.

The body can be combined with different lenses, viewfinders, focusing screens, and film magazines. This allows the camera to be configured for a particular subject or assignment.

The Hasselblad 500C/M is a defining example.

With an A12 film magazine loaded with 120 film, it records twelve square 6 × 6 photographs. A second magazine can hold another film stock or sensitivity, allowing the photographer to change recording material without finishing the first roll.

The waist-level finder can be replaced with an eye-level prism. Lenses and focusing screens can also be selected independently.

This made the V System a photographic platform rather than a fixed camera. The body could move between different films, lenses, viewing methods, and assignments while preserving the same mechanical foundation.

Choosing Your First Medium Format Film Camera

A first medium format camera should be selected according to how it will be used, rather than by reputation alone.

The frame format determines the proportions of the photograph and the number of exposures on each roll. A 645 camera provides more frames and a familiar rectangle. A 6 × 6 camera creates a square composition. Larger formats provide more negative area but fewer exposures.

The viewfinder has an equally strong influence on the experience. A waist-level finder is observed from above and usually presents a laterally reversed image. An eye-level prism feels closer to a conventional SLR. A rangefinder provides a bright optical view separate from the taking lens.

Whenever possible, handle the camera before purchasing it. The relationship between the finder, controls, weight, and subject is difficult to understand from specifications alone.

Lens, Film Back, and Metering

A fixed-lens camera provides a self-contained system. An interchangeable-lens camera offers a broader range of perspectives but requires attention to lens availability, condition, maintenance, and service support.

Interchangeable film magazines allow several rolls to be prepared in advance. One back may contain color film while another holds black-and-white film or a different ISO.

A fixed back is simpler, although the loaded roll usually needs to be completed before another film can be used.

Metering varies between systems. Some cameras include a built-in meter, others support a metered prism, and fully mechanical models may require a handheld meter or metering application.

Accurate exposure information is especially useful while learning the response of a new camera and film stock.

Condition and Serviceability

Most medium format film cameras are purchased used, so mechanical condition should take priority over cosmetic appearance.

Key areas to assess include:

• consistent shutter operation;

• smooth film advance;

• even frame spacing;

• secure film-magazine attachment;

• clear lens glass;

• clean aperture operation;

• accurate focusing;

• intact light seals;

• available service support.

A known service history is valuable. A camera with visible signs of use but reliable mechanics may be a stronger choice than a cleaner example with uncertain internal condition.

Choosing and Shooting Your First Roll of 120 Film

A first roll involves three practical decisions: which film to use, how to load it, and how it will be processed.

Choosing a Film Stock

Color negative film is commonly processed using C-41 chemistry. It generally provides useful exposure latitude and is widely supported by laboratories.

Black-and-white negative film emphasizes light, form, texture, and tonal structure. It can be processed professionally or developed at home with suitable equipment and chemistry.

Color transparency film, also called slide film, produces a positive image that can be viewed directly. It usually requires more precise exposure than color negative film.

For a first roll, choose a film that can be processed reliably by the laboratory you intend to use. Select an ISO suited to the expected light and to the shutter speeds and apertures available on the camera.

Loading and Exposing the Roll

Loading procedures vary, so the camera manual should remain the primary reference.

A typical process is:

1. Load the camera away from strong direct sunlight.

2. Place the fresh roll in the supply position.

3. Move an empty spool to the take-up side if required.

4. Draw the backing-paper leader across the film path.

5. Insert it securely into the take-up spool.

6. Wind while maintaining even tension.

7. Align the start arrow with the camera’s loading mark.

8. Close the back or film magazine.

9. Advance to frame one.

10. Set or record the film ISO.

11. Meter the scene.

12. Confirm focus, aperture, shutter speed, and framing.

13. Advance fully after each exposure.

Some cameras use alignment arrows, while others rely on a viewing window or a different advance mechanism. Follow the instructions for the specific model.

Finishing and Unloading the Roll

120 film does not rewind into its original spool.

After the final exposure, continue advancing until the film and backing paper have transferred fully onto the take-up spool. The paper wraps around the exposed film and protects it from light.

Remove the roll away from strong direct sunlight, keep it tightly wound, and secure it using the attached sealing strip.

The empty supply spool becomes the take-up spool for the next roll.

Label the exposed roll with the film type, ISO, date, camera, and project before sending it for processing.

Developing, Scanning, and Printing 120 Film

Development reveals the image recorded on the film. Scanning or darkroom printing determines how that image is presented.

Before sending a roll to a laboratory, confirm that it accepts 120 film and supports the required process:

• C-41 for most color negative films;

• black-and-white processing for monochrome films;

• E-6 for most color transparency films.

A standard scan may be sufficient for review and online use. A higher-resolution scan provides more flexibility for editing, cropping, and printing.

Scanner focus, optics, resolution, film flatness, dust removal, color conversion, and operator decisions all affect the digital file. A basic scan may not reveal all the detail and tonal information held in the negative.

Digital editing is a normal part of a hybrid workflow. Exposure, color, contrast, dust, cropping, and local adjustments can be refined after scanning.

Store negatives in clearly labeled archival sleeves. The physical film remains the original record and can be scanned or printed again.

Optical darkroom printing and digital printing from a scan offer different interpretations of the same negative. Both involve decisions about contrast, tone, scale, paper, and presentation.

The Ongoing Cost of Medium Format Film Photography

The investment in medium format film photography extends beyond the camera. It includes film, processing, scanning or printing, archival storage, shipping where required, and periodic maintenance.

Because a roll of 120 provides fewer exposures than a roll of 35mm film, the cost per photograph is generally higher. The total depends on the film stock, frame format, laboratory, scan quality, and printing requirements.

Home development can reduce some laboratory costs, particularly for black-and-white film, but requires equipment, chemistry, space, and a consistent method.

Older cameras may also need periodic servicing. Shutters, film magazines, advance mechanisms, seals, and focusing components benefit from maintenance by an experienced technician.

In return, the photographer retains an original negative that can be stored, revisited, rescanned, or printed again.

A Digital Continuation of the Hasselblad Film System

Film and digital capture can be understood as different recording methods within the same modular tradition.

The Hasselblad V System was designed around interchangeable components. Its film magazine could be removed while the body, lens, finder, and focusing screen remained in place.

That principle continues in the Hasselblad 907X & CFV 100C.

The detachable CFV 100C digital back can be paired with the 907X camera body and many compatible V System film cameras. When attached to a classic body, it occupies the position of the film magazine and records a digital file.

Familiar mechanical controls remain part of the process. The lens, shutter, and body continue to shape the act of photographing, while the recording medium becomes digital.

The tilting display supports a viewing position reminiscent of waist-level composition. The photographer can look down into the frame and work with a measured relationship between camera, subject, and image.

The CFV 100C uses a 100-megapixel sensor, 16-bit color, and Hasselblad Natural Colour Solution to produce detailed files with controlled tonal and color transitions.

Its connection to the V System rests on modular construction, cross-generational compatibility, waist-level-inspired viewing, and attention to the finished photograph.

[cta: https://store-na.hasselblad.com/products/907x-cfv-100c]

Frequently Asked Questions

Do I Need to Shoot 35mm Before Trying 120 Film?

No. The principles of exposure, focus, and composition remain the same. The new elements are the loading method, frame format, viewing system, film advance, and processing workflow. Reading the camera manual and practicing the loading sequence are more useful than prior experience with another film size.

Do Medium Format Film Cameras Need Batteries?

It depends on the camera. Many mechanical cameras can expose film without a battery, although their meters or accessories may still require power. Cameras with electronically controlled shutters, built-in meters, or motorized advance systems generally depend on batteries.

Can Any Medium Format Camera Use 120 Film?

No. Many medium format cameras use 120 film, while others were designed for 220, 620, 70mm, sheet film, or proprietary formats. Some cameras accept more than one type with a specific back or insert. Confirm the supported film and spool specification before loading the camera.

Can Scanned 120 Film Be Edited Digitally?

Yes. Once scanned, the image can be edited using conventional photography software. Exposure, color, contrast, dust, cropping, and local adjustments can be refined while the physical negative remains available for future scanning or printing.
